| Specifications | |
|---|---|
| Bosch 10 Digit Number | 0242140566 |
| Thread Length (mm) | 26.5 |
| Diameter Center Electrode (mm) | 0.8 |
| Electrode Gap (mm) | 0.7 |
| Hex Size (mm) | 14 |
| Center Electrode Core Material | NiCrFe+Cu |
| Center Electrode Tip Material | Ir |
| Ground Electrode Material | Pt+NiCrFe+Cu |
| Seal seat | flat-solid |
| Max. Tightening Torque (Nm) | 23 |
| Thread (mm) | M 12 x 1.25 |
