LED ROUND WORKLAMP FLOOD BEAM 9 - 36V 12W 4 LED's BLACK HOUSING
Ignite 2" Round LED Worklamp 9 - 36 Volt 12 Watt
60° Flood (Spread) Beam Pattern
4 x 3 Watt High Intensity LP LED's
1,000 Raw Lumens, 850 Effective Lumens and 6,000K
1 Lux @ 42m and 1,760cd Peak Beam Intensity
Current Draw: 1amp @ 12 Volt and 0.5amp @ 24 Volt
Patented Multi-Surface Polycarbonate TIR Optical System Reflector Technology with Polycarbonate Lens
Integrated Electronic Thermal Management (ETM)
Black Anondised Polyester Powder Coated Die-Cast Aluminium Alloy (ADC12) Housing with integrated Heat-Sink
Stainless Steel (SUS304) Single Bolt Mount Bracket and Hardware
300mm Lead with 2 Pin Deutsch Plug
Over and Under Voltage Protection
Reverse Polarity Protection
UV, Water and Shock resistant up to 20G
50,000 Hours LED Lifespan
ECE R10, CE Approved and EMC Compliant, CISPR 25 Class 3 Certified
IP68 and IP69K Rating
Environment Temperature: -40°C ~ +60°C
8 Year Warranty
Notes:
IWL0403FA is Amber LED variant
