RACEWORKS 980CC RACEWORKS (MODIFIED BOSCH) FULL LENGTH INJECTOR
Modified/High Flowed Bosch Injector
Size: 980cc (95 Lb/hr) @ 3bar and 1150cc (110Lb/hr) @ 4bar.
Impedance: High (12 Ohms)
Plug: USCAR. Top O-Ring: 11mm.
Ethanol Methanol Safe
Spray Pattern: Narrow Cone
Spray Direction: Straight
Flow variance is +/- 1.5% (3% Total)
Download Injectors Size Charts PDF
FLYWHEEL POWER FIGURES (ESTIMATED) PER INJECTOR
| Normally Aspirated Gasoline | 185HP | 140KW |
| Forced Inducted Low Boost Gasoline | 155HP | 115KW |
| Forced Inducted High Boost Gasoline | 165HP | 125KW |
| Normally Aspirated E85 | 140HP | 105KW |
| Forced Inducted Low Boost E85 | 110HP | 80KW |
| Forced Inducted High Boost E85 | 120HP | 90KW |
