FX-R Low Pressure Fuel Regulator (-6AN Ports)
FUEL DELIVERY€¦.DELIVERED!
The GFB FX-R is a low pressure bypass type regulator intended for use on carburetors that are fed by an EFI type pump.
FX-R LOW PRESSURE FUEL REGULATOR FEATURES:
- 2x -6AN inlet port, 2x 1/8€� NPT pressure gauge/sensor ports, and 1x -6AN return port
- Adjustable from 3-13psi
- Flows 1380 LPH @7psi
- Double layer/double reinforced diaphragms with a burst strength exceeding 500psi
- Teflon co-polymer seat with spherical stainless valve to retain fuel pressure longer after shut down
- Pressure reference port for blow-through boosted applications
- Completely serviceable
