TI AUTOMOTIVE (WALBRO) GSL396 FUEL PUMP 350LPH HIGH PRESSURE
TI AUTOMOTIVE (WALBRO) Part Number: GSL396
Type: Universal Inline Fuel Pump - External
Fuel: Petrol
Horsepower: 800HP (NA)
Flow Rate: 350LPH High Pressure
TI Automotive's newest addition to the popular inline fuel pump family, the TI AUTOMOTIVE (WALBRO) GSL396. TI AUTOMOTIVE (WALBRO) / Ti Automotive GSL396 350LPH Inline Fuel Pump is the newest inline pump released by TI (formerly known as TI AUTOMOTIVE (WALBRO)). Ti Automotive has released the TI AUTOMOTIVE (WALBRO) GSL 396 inline fuel pumps, an upgrade to their popular GSL392 pump for those with engines requiring more fuel flow for higher horsepower applications. Capable of supporting up to 800HP @ 40PSI and 13.5V. Identical 1x10mm female threading on the inlet and outlet. The compact package makes for an easy upgrade, nearly the same overall shape, and dimension as the GSL392. (GSL396 is 2.5mm longer) GSL396 fuel pump can be used in vehicles for racing or performance purposes where higher pressure fuel is necessary. Turbocharged, Supercharged.- with faulty inline fuel pumps, expensive or hard to replace in-tank fuel pumps. The GSL396 is rated at 350 LPH (650 hp) of flow when set at 40 PSI with an input voltage of 13.5 volts. Features 10-mm x 1-mm threading on the inlet and outlet, allowing for easy installation or upgrading from one of the companys other popular inline pumps.
TI AUTOMOTIVE (WALBRO) GSL396 350LPH High-Pressure Inline Fuel Pump is due to soon become very popular with upgrades to vehicles with engine and performance modifications, supporting up to 800 horsepower. - Pressure: 350(LPH) Liters Per Hour- AMP: 20 - OE-proven second generation. - Fits most EFI applications including turbo and supercharged. - Variety of pressures and flows available, including high-pressure performance.- All metal shell including inlet and outlet. - 10mm x 1mm threaded inlet and outlet accept a variety of fittings.
The 400-939 kit includes two standard universal fittings which can connect to any 5/16 inch hose.- Lightweight, compact design. - QS9000 certified. - Made in USA (400-939 sold separately)
Flow data as follows: ( See the GSL396 Flow Chart Graph below for details)
Free Flow: 85 GPH | 322 LPH
43.5 PSI: 79 GPH | 300 LPH NA Gasoline: 769 HP Boosted Gasoline: 638 HP
60 PSI: 77 GPH | 292 LPH NA Gasoline: 749 HP Boosted Gasoline: 621 HP
Gasoline Only, No E-85 (Just like the GSL392 and other inline pumps in the GSL family.)
Note! This pump should never be operated without a fuel filter between the tank and the pump. This pre-filter should be 20- to 40-microns. Additionally, almost all applications require a 10-micron post-filter between the fuel pump and the fuel rail. Putting just a 10-micron filter before the pump is not recommended. We offer a good quality metal canister filter (disposable) with 3/8-inch hose barb ends as well as the outstanding Holley aluminium billet 390 LPH filter with -6 and -8 AN fittings. The Holley filter can be disassembled and cleaned or the entire filter media renewed.
TI AUTOMOTIVE (WALBRO) inline fuel pumps are ideal universal fuel pump replacements and upgrades for:
Vehicles with faulty inline fuel pumps
Upgrades to EFI from mechanical fuel pumps
Other Vehicles where higher fuel flow is necessary and an in-tank pump is not required.
Inline fuel pump specs:
OE-proven second generation
Fits most EFI applications including turbo and supercharged
Variety of pressures and flows available, including high-pressure performance
All metal shell including inlet and outlet
10mm x 1mm threaded inlet and outlet accept a variety of fittings
Lightweight, compact design
QS9000 certified
