BOSCH Fuel Pump
THE KING IS DEAD!
LONG LIVE THE KING!!
News effective 21.06.2021
The Bosch 0580254044 pump can no longer be manufactured. The tooling and equipment was old and it was not feasible to be replaced. Bosch however, has designed an alternative that will have some technical differences but the performance will be similar. Basic flow rates are provided on page 2.
The key differences will be:
1. Outside diameter.
2. Hydraulic connectivity.
3. Connector Terminals will differ so connections will need minor adaptation to suit.
The BOSCH 0 580 464 200 is HERE NOW!
Description
- >275l/h @ 5bar
- Supercedes the 0 580 254 044
- Flows ~10% higher than 044 at 7bar
- Weighs 15% less than 044 at 860g
- Current draw similar to 044
- M18x1.5 inlet fitting and M12x1.5 outlet fitting
- External non return valve
- Pressure relief valve 8-10bar
- Not suitable for voltage regulation
- Compatible with Gasoline and Diesel
